INTRODUCTION
2 STS320
POWER REQUIREMENTS
The STS320 solution kit doesn’t include a power supply unit, which has to be ordered
separately. The maximum power required depends on the model.
Power is supplied to the system through its connection box CBX500.
The following table indicates the compatible power supply to use according to the
S
TS320 model. The supply current consumption values are given considering the default
parameter settings with the array working at maximum throughput.
Model Order No.
Max. Supply Current
@ 24 V ± 10%
Top Reading Passenger Car and Light Truck Solution
STS320-003 TIRE SORT 3_HEAD ST RES 938100001 3.1 A max.
STS320-004 TIRE SORT 4_HEAD ST RES 938100002 4.1 A max.
STS320-004 TIRE SORT 5_HEAD ST RES 938100003 5.1 A max.
STS320-013 TIRE SORT 3_HEAD HI RES 938100004 3.1 A max.
STS320-014 TIRE SORT 4_HEAD HI RES 938100005 4.1 A max.
STS320-015 TIRE SORT 5_HEAD HI RES 938100006 5.1 A max.
STS320-016 TIRE SORT 6_HEAD HI RES 938100007 6.0 A max.
Top Reading Commercial Vehicle Solution
STS320-103 TIRE SORT 3_HEAD ST RES LR 938100008 3.1 A max.
STS320-104 TIRE SORT 4_HEAD ST RES LR 938100009 4.1 A max.
STS320-113 TIRE SORT 3_HEAD HI RES LR 938100010 3.1 A max.
STS320-114 TIRE SORT 4_HEAD HI RES LR 938100011 4.1 A max.
STS320-115 TIRE SORT 5_HEAD HI RES LR 938100012 5.1 A max.
STS320-116 TIRE SORT 6_HEAD HI RES LR 938100013 6.0 A max.
Near Reading and Bottom Reading Solution
STS320-203 TIRE SORT 3_HEAD ST RES NR 938100014 3.1 A max.
STS320-204 TIRE SORT 4_HEAD ST RES NR 938100015 4.1 A max.
STS320-205 TIRE SORT 5_HEAD ST RES NR 938100016 5.1 A max.
NOTE
The suggested Power Supply for all models is PWR-240B (order no.
93ACC0264). For STS320-xx3 and STS320-xx4, we also suggest PWR-
120 (order no. 93ACC0246).
