After Sales level - #INFORMATION menu
Parameter Description
NUMBER REMOT A
Remote control version number
NUMBER REMOT B
Remote control version number
NUMBER REMOT C
Remote control version number
CALIBRA.CLOCK
(2)
Clock calibration
(1) The parameter is only displayed for the options, circuits or sensors actually connected
(2) The parameter is only displayed if INSTALLATION is set to EXTENDED
After Sales level - #CONFIGURATION Menu
Parameter Adjustment range Description
MODE:
MONO / ALL.CIRC To chose if the exemption made for one remote control applies to a single circuit
(MONO) or if it must be transmitted to a group of circuits (ALL.CIRC)
TYPE
AUTODETECTION OFF / ON
System reset if error L38 is displayed
TAS OFF / ON
Activation of the Titan Active System® function
DFDU
Generator type
ENERGY METER OFF / ON
Activation of the Nominal Energy Estimate function
MAX HEAT OUTP
maximum permitted heating capacity
MAX DHW OUTP.
maximum permitted domestic hot water flow
MIN OUTP.
Minimum permitted capacity
RESET CNT.kWh OFF / ON
Reset the heating and DHW energy meters
7.6.1. Control system sequence
Control system sequence
Status Sub-status Operation
0 Rest 0 Rest
1 Boiler start (Heat demand) 1 Anti-short cycle activated
2 Open isolating valve
3 Start-up of the boiler pump
4 Wait for the correct temperatures for burner start
2 Burner start 10 Open gas valve (External)
11 Fan start-up
12 Opening of the flue gas flue damper
13 Preventilation
14 Awaiting closure of the RL contact (if the function is activated)
15 Burner on switch request
16 Leak proofing system test
17 Pre-ignition
18 Ignition
19 Check flame presence
20 Inter-ignition time delay
7. Troubleshooting Diematic iSystem For C 330 / C 630 ECO
83
31082018 - 7600691-001-06
