Figure 37 Installing the controller
Transferring disks and disk filler modules
Starting with the disk or disk filler module in slot 0, transfer disks and any disk filler modules one at
a time from the faulted enclosure to the replacement enclosure.
NOTICE Make sure to transfer the disks and any disk filler modules to the same slots in the
replacement enclosure that they occupied in the faulted enclosure. Installing disks out of their
original order results in data unavailability, and possible data loss.
Removing a disk
About this task
Refer to Figure 38 on page 47 while performing the procedure that follows.
Procedure
1.
Pull the latch on the disk up.
2. Slowly pull the disks from its slot.
3. Place the disk on a static-free surface.
Removing and replacing FRUs
46 Dell EMC ES40 Expansion Shelf Guide Field Replacement Unit Guide
