S5200F-ON Series switch

Installation

To install the S5200F-ON Series (S5232F-ON, S5248F-ON, S5296F-ON, S5224F-ON, and

S5212F-ON) switch, complete the installation procedures in the order presented in this

section.

Always handle the switch and its components with care. Avoid dropping the switch or any

eld replaceable units (FRUs).

NOTE: ESD damage can occur if components are mishandled. Always wear an ESD-

preventive wrist or heel ground strap when handling the switch and its components.

As with all electrical devices of this type, take all the necessary safety precautions

to prevent injury when installing this switch.

Topics:

• Unpack

• Ground cable

• Rack or cabinet installation

• One-half U front-rack installation

• One U ReadyRails installation

• Two U four-post rack assembly

• DC power connections

• S5212F-ON only DC power connections

• Optics installation

• Switch power-up

• After switch installation

S5200F-ON Series switch Installation 11

Dell EMC S5200F-ON Series User Manual
