Dell EMC S5200F-ON Series User Manual

To remove each rail, pull on the latch release button on each ange ear and unseat each rail.
Two-post ush-mount installation
NOTE: For more installation instructions, see the installation labels attached to the
rail assembly.
1 For this conguration, remove the latch castings from the front side of each
ReadyRails assembly, item 1.
To remove the two screws from each front ange ear on the switch side of the rail and
remove each latch casting, use a Torx screwdriver. Retain the latch castings for future
rack requirements. It is not necessary to remove the back ange castings.
22 S5200F-ON Series switch Installation
