Parts Catalog 7-3

Assembly 1: Covers

Asm-

Index

Part

number

Units/

mach

Units/

FRU

Description

1-1 40X5827 1 1 Mid rear cover

2 40X5839 1 1 Rear door

3 40X5838 1 1 Rear cover

4 40X5820 1 1 Rear left frame assembly

5 40X5821 1 1 Rear right frame assembly

6 40X5822 1 1 Right side cover

7 40X5379 1 1 Front door cover

8 40X5448 1 1 Nameplate cover

9 40X5806 1 1 Lower AIO access assembly

10 40X5778 1 1 Front access door cover

11 40X5823 1 1 Left side cover

12 40X5614 1 1 Top cover assembly

13 40X5811 1 1 Tub cover assembly

14 40X5809 1 1 USB cable mount bracket

15 40X5834 1 1 Output bin LED lens

16 40X5835 1 1 Output bin LED

17 40X5815 2 1 Op panel support

18 40X5814 2 1 Display rotation support

NS 40X5381 1 1 Primary tray
