Parts Catalog 7-5

Assembly 2: Imaging

Asm-

Index

Part

number

Units/

mach

Units/

FRU

Description

1 40X5471 1 1 ADF Separator roll

2 40X5472 1 1 ADF Separator pad

3 40X5470 1 1 ADF input tray

4 40X5540 1 1 ADF cable

5 40X5824 1 1 Duplex ADF unit

6 40X5804 1 1 Flatbed cushion

7 40X5825 1 1 Flatbed module

8 40X5818 1 1 Right scanner cover

9 40X5743 1 1 Operator panel button assembly

10 40X5810 1 1 UICC Cable (Operator panel cable)

11 40X5831 1 1 Operator panel USB cable

12 40X5826 1 1 Scanner front cover

13 40X5837 1 1 Op panel display

14 40X0399 1 1 Op panel display bezel X463

14 40X0401 1 1 Op panel display bezel X466

15 40X5813 1 1 Kickstand support

16 40X5819 1 1 Left scanner cover

NS 40X5807 1 1 ADF maintenance kit

14 40X0400 1 1 Op panel display bezel X464 / 3333dn, 3335dn
