Removing the power-adapter port
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-7E5DC50B-52E4-450D-A406-E41951E197AB
Status Released
Prerequisites
1 Remove the base cover.
2 Remove the wireless card.
Identifier GUID-ACE3C9FD-E00F-4031-8DCA-A234DFD9F1D3
Status Released
Procedure
Applicable on computers that are shipped with power button only.
1 Remove the three screws (M2.5x6) that secure the right hinge to the system board and palm rest assembly.
2 Lift the right hinge.
3 Disconnect the power-adapter port cable from the system board.
4 Peel and lift the power-adapter port along with its cable o the palm rest and keyboard assembly.
23
Removing the power-adapter port 49
