Identifier GUID-A7F798E1-C24C-44A0-9D6E-60A24BC170F6
Status Released
Replacing the palm-rest and keyboard assembly
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-CACCF417-6678-4C23-8898-014D62DDE1C2
Status Released
Procedure
Place the palm rest and keyboard assembly on a at surface.
Identifier GUID-65085855-278E-45CA-BCA6-C963F4F2C410
Status Released
Post-requisites
1 Replace the power button with ngerprint reader (optional).
2 Replace the system board.
3 Replace the power-button board.
4 Replace the I/O board.
5 Replace the display assembly.
6 Replace the power-adapter port (optional).
7 Replace the touchpad.
8 Replace the hard drive.
9 Replace the speakers.
10 Replace the wireless card.
11 Replace the solid-state drive/Intel Optane.
12 Replace the fan.
13 Replace the battery.
14 Replace the base cover.
40
86 Replacing the palm-rest and keyboard assembly
