Replacing the power button with ngerprint
reader
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
NOTE: Applicable only for computers that are shipped with ngerprint reader.
Identifier GUID-7149B903-B51D-44C2-A6F0-66161E60EC30
Status Released
Procedure
1 Using the alignment posts, align the power button on the palm rest and keyboard assembly.
2 Slide and place the power button into the slots on the palm rest and keyboard assembly.
3 Replace the screw (M2x2) that secures the power button to the palm rest and keyboard assembly.
4 Adhere the ngerprint reader cable on the palm rest and keyboard assembly.
38
82 Replacing the power button with ngerprint reader
