Dell Inspiron 9400 User Manual


5. Remove the hinge cover (see Removing the Hinge Cover).

6. Use the pull-tab to disconnect the display cable from the system board, and then disengage the display cable from the cable channel.

7. Remove the four M2.5 x 5-mm screws (two on each side) that connect the display to the computer base.

8. Lift the display assembly away from the computer.

Replacing the Display Assembly

1. Thread the Mini-Card antenna cables back through the hole in the base of the computer so that they are accessible from the bottom of the computer.
1
display cable in cable channel
2
display cable pull-tab
3
M2.5 x 5-mm screws (4)
1
Mini-Card antenna cables
NOTICE: When removing the display assembly, carefully unthread the Mini-Card antenna cables through the computer base.

Dell Inspiron 9400 Specifications

General

Hard Drive Interface	SATA
Battery	6-cell or 9-cell Lithium Ion
Processor	Intel Core Duo T2400 / T2500
RAM	Up to 2GB DDR2 SDRAM
Display	17-inch WXGA+ (1440x900) or WUXGA (1920x1200)
Graphics	NVIDIA GeForce Go 7800
Optical Drive	DVD+/-RW
Operating System	Windows XP Media Center Edition or Windows XP Professional
Chipset	Intel 945PM Express
Wireless	Intel PRO/Wireless 3945ABG
Dimensions	15.5 x 11.3 x 1.6 inches
Storage	60GB / 80GB / 100GB / 120GB 5400RPM or 100GB 7200RPM
