Dell Inspiron 9400 User Manual


7. Repeat step 6 for the lower-left corner of the bezel. Then use your fingers to release the snaps around the rest of the bezel and lift it away from the
display panel.

Replacing the Display Bezel

1. Starting at any corner, use your fingers to gently snap the bezel into place to secure it to the display panel.

2. Replace the four M2.5 x 5-mm screws on the corners of the bezel.

3. Replace the four shoulder screws and two screw covers.

4. Replace the six rubber screw-covers/display bumpers around the bezel.
Display Panel

Removing the Display Panel
1
display back cover
2
tabs


1
display bezel
2
display panel

Dell Inspiron 9400 Specifications

General

Hard Drive Interface	SATA
Battery	6-cell or 9-cell Lithium Ion
Processor	Intel Core Duo T2400 / T2500
RAM	Up to 2GB DDR2 SDRAM
Display	17-inch WXGA+ (1440x900) or WUXGA (1920x1200)
Graphics	NVIDIA GeForce Go 7800
Optical Drive	DVD+/-RW
Operating System	Windows XP Media Center Edition or Windows XP Professional
Chipset	Intel 945PM Express
Wireless	Intel PRO/Wireless 3945ABG
Dimensions	15.5 x 11.3 x 1.6 inches
Storage	60GB / 80GB / 100GB / 120GB 5400RPM or 100GB 7200RPM
