Dell Latitude D530 User Manual

About Your Computer 27
Right Side View
MEDIA BAY — You can install devices such as an optical drive, second battery, or a
Dell TravelLite™ module in the media bay.
DEVICE LATCH RELEASE — Press the latch release to eject any device installed in the
media bay.
USB
CONNECTORS
Back View
1 media bay 2 device latch release
3 USB connectors (2)
Connect USB devices, such as a mouse, keyboard, or
printer.
1 23
8123 4 5 6 7

Dell Latitude D530 Specifications

General

Processor	Intel Core 2 Duo
RAM	Up to 4 GB DDR2
Graphics	Intel GMA X3100
Chipset	Intel GM965
Hard Drive Interface	SATA
Optical Drive	DVD-ROM or DVD+/-RW
Battery	6-cell or 9-cell Lithium-Ion
Display	14.1 inch
Display Resolution	1280 x 800 (WXGA)
Operating System	Windows XP
Ports	4 x USB 2.0, VGA, Ethernet, Modem, Headphone, Microphone
Wireless	802.11a/g
Weight	5.5 lbs (2.49 kg)
