Dell Latitude D530 User Manual

About Your Computer 31
Bottom View
MEMORY MODULE/MODEM/WLAN MINI-CARD/COIN-CELL BATTERY COVER —
Covers the compartment that contains one memory module, the modem, the WLAN
Mini-Card, and the coin-cell battery.
1memory
module/modem/WLAN
Mini-Card/coin-cell battery
cover
2 battery-bay latch release
3 battery charge
gauge/health gauge
4 battery
5 docking-device connector 6 air vents
7 hard drive
1
5
4
2
7
3
6

Dell Latitude D530 Specifications

General

Processor	Intel Core 2 Duo
RAM	Up to 4 GB DDR2
Graphics	Intel GMA X3100
Chipset	Intel GM965
Hard Drive Interface	SATA
Optical Drive	DVD-ROM or DVD+/-RW
Battery	6-cell or 9-cell Lithium-Ion
Display	14.1 inch
Display Resolution	1280 x 800 (WXGA)
Operating System	Windows XP
Ports	4 x USB 2.0, VGA, Ethernet, Modem, Headphone, Microphone
Wireless	802.11a/g
Weight	5.5 lbs (2.49 kg)
