Dell Latitude D530 User Manual

74 Using Multimedia
4 Plug all three connectors from the other end of the component video cable
into the component video-input connectors on the TV. Make sure that the
red, green, and blue colors of the cable match the colors of the TV input
connectors.
5 Plug the single-connector end of the audio cable into the headphone
connector on the computer.
6 Plug the two RCA connectors on the other end of the audio cable into the
audio input connectors on your TV or audio device.
7 Turn on the TV, turn on any audio device that you connected (if
applicable), and then turn on the computer.
8 See "Enabling the Display Settings for a TV" on page 78 to ensure that the
computer recognizes and works properly with the TV.
Component Video and S/PDIF Digital Audio
1 component video adapter 2 component video cable
1 S-video TV-out connector 2 component video adapter
1 2

Dell Latitude D530 Specifications

General

Processor	Intel Core 2 Duo
RAM	Up to 4 GB DDR2
Graphics	Intel GMA X3100
Chipset	Intel GM965
Hard Drive Interface	SATA
Optical Drive	DVD-ROM or DVD+/-RW
Battery	6-cell or 9-cell Lithium-Ion
Display	14.1 inch
Display Resolution	1280 x 800 (WXGA)
Operating System	Windows XP
Ports	4 x USB 2.0, VGA, Ethernet, Modem, Headphone, Microphone
Wireless	802.11a/g
Weight	5.5 lbs (2.49 kg)
