Dell Latitude D530 User Manual

72 Using Multimedia
6 Plug the other end of the digital audio cable into the S/PDIF input
connector on your TV or other audio device.
7 Turn on the TV, turn on any audio device that you connected (if
applicable), and then turn on the computer.
8 See "Enabling the Display Settings for a TV" on page 78 to ensure that the
computer recognizes and works properly with the TV.
Component Video and Standard Audio
1 composite video adapter 2 S/PDIF digital audio cable
1 S-video TV-out connector 2 component video adapter
1 2
2
1

Dell Latitude D530 Specifications

General

Processor	Intel Core 2 Duo
RAM	Up to 4 GB DDR2
Graphics	Intel GMA X3100
Chipset	Intel GM965
Hard Drive Interface	SATA
Optical Drive	DVD-ROM or DVD+/-RW
Battery	6-cell or 9-cell Lithium-Ion
Display	14.1 inch
Display Resolution	1280 x 800 (WXGA)
Operating System	Windows XP
Ports	4 x USB 2.0, VGA, Ethernet, Modem, Headphone, Microphone
Wireless	802.11a/g
Weight	5.5 lbs (2.49 kg)
