Dell Latitude D530 User Manual

Using Multimedia 77
4 Click the DVD option.
5 Click the DVD Audio Setting icon.
6 Click the arrows beside the Speaker Configuration setting to scroll
through the options, and select the
SPDIF option.
7 Click the Back button once, and then click the Back button again to
return to the main menu screen.
Enabling S/PDIF in the Windows Audio Driver
1 Double-click the speaker icon in the Windows notification area.
2 Click the Options menu and then click Advanced Controls .
3 Click Advanced .
4 Click S/PDIF Interface .
5 Click Close .
6 Click OK .
Setting Up the Cyberlink (CL) Headphones
NOTE: The CL headphone feature is available only if your computer has a DVD
drive.
If your computer has a DVD drive, you can enable digital audio for DVD
playback.
1
Launch the Cyberlink PowerDVD program.
2 Insert a DVD into the DVD drive.
If the DVD begins playing, click the stop button.
3 Click the Settings option.
4 Click the DVD option.
5 Click the DVD Audio Setting icon.
6 Click the arrows beside the Speaker Configuration setting to scroll
through the options, and select the
Headphones option.
7 Click the arrows beside the Audio listening mode setting to scroll through
the options, and select the
CL Headphone option.
8 Click the arrows beside the Dynamic range compression option to select
the most suitable option.

Dell Latitude D530 Specifications

General

Processor	Intel Core 2 Duo
RAM	Up to 4 GB DDR2
Graphics	Intel GMA X3100
Chipset	Intel GM965
Hard Drive Interface	SATA
Optical Drive	DVD-ROM or DVD+/-RW
Battery	6-cell or 9-cell Lithium-Ion
Display	14.1 inch
Display Resolution	1280 x 800 (WXGA)
Operating System	Windows XP
Ports	4 x USB 2.0, VGA, Ethernet, Modem, Headphone, Microphone
Wireless	802.11a/g
Weight	5.5 lbs (2.49 kg)

Summary

About Your Computer

Front View

Identification of components on the computer's front panel.

Left Side View

Identification of ports and connectors on the computer's left side.

Right Side View

Back View

Bottom View

Setting Up Your Computer

Using a Battery

Battery Performance and Management

Understanding battery life, conservation, and power management modes.

Checking Battery Status

Monitoring battery charge level, health, and status indicators.

Charging and Replacing Batteries

Procedures for charging, replacing, and storing the computer battery.

Using the Keyboard

Keyboard Shortcuts and Key Combinations

Touch Pad Operation and Customization

Using the Display

Adjusting Display Settings

Using External Displays

Setting Up and Using Networks

Network Connection Basics

Connecting the computer to wired and wireless networks.

Wireless Network Setup (WLAN/WWAN)

Configuring wireless local and wide area network connections.

Microsoft Windows Firewall

Securing Your Computer

Password Management

Setting and managing system, administrator, and hard drive passwords.

Trusted Platform Module (TPM)

Hardware-based security feature for encryption and key management.

Security Management Software

Troubleshooting

Dell Diagnostics

Running diagnostic tests to identify hardware problems.

Dell Support Utility

Using the utility for self-support, updates, and system health scans.

Common Problem Areas

Troubleshooting common hardware and software issues.

System Setup Program

System Setup Overview

Changing Boot Sequence and Ports

Configuring boot order, COM ports, and enabling system features.

Reinstalling Software

Drivers

Understanding the role and identification of device drivers.

Reinstalling Drivers and Utilities

Procedures for reinstalling drivers and system utilities.

Restoring Your Operating System

Methods for restoring the operating system and system state.
