Dell Latitude D530 User Manual

Using the Keyboard 49
Power Management
Speaker Functions
Microsoft
®
Windows
®
XP Logo Key Functions
<Fn><Esc> Activates a power management mode.
You can reprogram this keyboard shortcut
to activate a different power management
mode using the Advanced tab in the
Power Options Properties window.
<Fn><F1> Puts the computer into hibernate mode.
Dell QuickSet is required.
<Fn><Page Up> Increases the volume of the integrated
speakers and external speakers, if
attached.
<Fn><Page Dn> Decreases the volume of the integrated
speakers and external speakers, if
attached.
<Fn><End> Enables and disables the integrated
speakers and external speakers, if
attached.
Windows logo key and <m> Minimizes all open windows
Windows logo key and <Shift><m> Restores all minimized windows. This key
combination functions as a toggle to
restore minimized windows following the
use of the Windows logo key and <m>
key combination.
Windows logo key and <e> Runs Windows Explorer.
Windows logo key and <r> Opens the Run dialog box.
Windows logo key and <f> Opens the Search Results dialog box.
Windows logo key and <Ctrl><f> Opens the Search Results-Computer
dialog box (if the computer is connected
to a network).
Windows logo key and <Pause> Opens the System Properties dialog box.

Dell Latitude D530 Specifications

General

Processor	Intel Core 2 Duo
RAM	Up to 4 GB DDR2
Graphics	Intel GMA X3100
Chipset	Intel GM965
Hard Drive Interface	SATA
Optical Drive	DVD-ROM or DVD+/-RW
Battery	6-cell or 9-cell Lithium-Ion
Display	14.1 inch
Display Resolution	1280 x 800 (WXGA)
Operating System	Windows XP
Ports	4 x USB 2.0, VGA, Ethernet, Modem, Headphone, Microphone
Wireless	802.11a/g
Weight	5.5 lbs (2.49 kg)
