Dell OptiPlex 360 User Manual

16 Before Working on Your Computer
1 internal chassis
speaker connector
(optional)
2 power connector 3 memory module
connectors (DIMM1,
DIMM2)
4 serial ATA drive
connectors (SATA0,
SATA1, SATA2)
5 main power connector 6 floppy drive connector
7 audio connectors (2) 8 network adapter
connector, USB ports
(2)
9 USB ports (4)
10 VGA video connector 11 RTC reset jumper
(RTCRS)
12 parallel (printer)
connector
13 serial connector 14 password jumper
(PSWD)
15 battery socket
16 system board speaker
(BEEP)
17 PCI Express x1
connectors (SLOT2,
SLOT 3)
18 PCI Express x16
connector (SLOT1)
19 serial connector 20 floppy drive connector
(DSKT)
21 processor fan
connector

Dell OptiPlex 360 Specifications

General

Processor	Intel Core 2 Duo, Intel Pentium Dual-Core, Intel Celeron
Chipset	Intel G31 Express
Networking	Integrated 10/100/1000 Ethernet
Memory	Up to 4GB DDR2 SDRAM
Storage	SATA hard drive, up to 500GB
Graphics	Integrated Intel GMA 3100
Optical Drive	DVD-ROM or DVD+/-RW
Operating System	Windows Vista, Windows XP
Form Factor	Mini Tower, Desktop
Audio	Integrated
Expansion Slots	PCI, PCIe x16
Ports	1 Serial, 1 Parallel, 1 VGA, 1 RJ-45, Audio in/out
