Dell OptiPlex 360 User Manual

Drives 67
3 Remove the optical drive and set it aside (see "Removing the Optical Drive
From the Desktop Computer" on page 59).
CAUTION: Do not pull the drive out of the computer by the drive cables. Doing so
may cause damage to cables and the cable connectors.
4 Pull up on the drive release latch and slide the floppy drive or media card
reader toward the back of the computer. Then, lift up to remove the drive
from the computer.
5 Disconnect the power and data cables from the back of the floppy drive or
media card reader.
6 If you are removing the floppy drive or media card reader permanently:
a Install the drive panel insert by lowering it into the drive bay until it
clicks into place.
b Remove the data cable from the system board and remove it from the
computer.
c Follow the procedure in "After Working on Your Computer" on
page 17.
d Enter the system setup program to update the drive configuration
information. For more information on using the system setup
program, see the
Dell Technology Guide on your computer or at
support.dell.com.
1 floppy drive or media card reader 2 drive release latch
1
2

Dell OptiPlex 360 Specifications

General

Processor	Intel Core 2 Duo, Intel Pentium Dual-Core, Intel Celeron
Chipset	Intel G31 Express
Networking	Integrated 10/100/1000 Ethernet
Memory	Up to 4GB DDR2 SDRAM
Storage	SATA hard drive, up to 500GB
Graphics	Integrated Intel GMA 3100
Optical Drive	DVD-ROM or DVD+/-RW
Operating System	Windows Vista, Windows XP
Form Factor	Mini Tower, Desktop
Audio	Integrated
Expansion Slots	PCI, PCIe x16
Ports	1 Serial, 1 Parallel, 1 VGA, 1 RJ-45, Audio in/out
