Page #208 background imageLoading...
Page #208 background image
Back to Contents Page
(FRONTPANEL)
(POWER1)
(INTRUDER)
10
CMOS reset jumper
(RTCRST)
11
battery socket
(BATTERY)
12
internal USB (USB1)
13
PCI Express x16
connector (SLOT1)
14
standby power
(AUX_PWR_LED)
15
PCI connector (SLOT2)
16
PCI Express x1
connector (SLOT4)
17
password jumper
(PSWD)
18
PCI connector (SLOT3)
19
floppy drive connector
(DSKT)
20
serial connector
(PS2/SER2)
21
Optional DVI-card connector
(DVI_HDR)
22
fan connector
(FAN_CPU)
