Replacing the battery
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at
www.dell.com/regulatory_compliance.
Procedure
1 Align the screw hole on the battery with the screw hole on the palmrest
and keyboard assembly.
2 Replace the screw that secures the battery to the palmrest and keyboard
assembly.
3 Connect the battery cable to the system board.
Post-requisites
Replace the base cover.
21
