Replacing the power and
volume-buttons board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at www.dell.com/regulatory_compliance.
Procedure
1 Place the power and volume-buttons board into the slot on the palmrest
and keyboard assembly.
2 Adhere the tape that secures the power and volume-buttons board to the
palmrest and keyboard assembly.
3 Connect the power and volume-buttons board cable to the I/O board.
Post-requisites
1 Replace the battery.
2 Replace the base cover.
24
