Replacing the sensor board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at
www.dell.com/regulatory_compliance.
Procedure
1 Align the sensor board on the display-back cover and snap the sensor
board into place.
2 Slide the sensor-board cable into the slot on the sensor board and press
down the latch to secure the cable.
Post-requisites
1 Replace the display panel.
2 Replace the display assembly.
3 Replace the wireless card.
4 Replace the battery.
5 Replace the base cover.
87
