2. Install the:
a. palmrest
b. hard drive
c. keyboard
d. battery
e. base cover
f. SD card
3. Follow the procedure in After working inside your computer.
Graphics card
Removing the graphics card
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. SD card
b. base cover
c. battery
d. keyboard
e. hard drive
f. palmrest
g. heatsink assembly
3. To remove the graphics card:
a. Remove the 2 (M2.0x3.0) screws that secure the beam connector to the system board [1].
b. Remove the beam connector from the system board [2].
Removing and installing components
69
