122 Jumpers and Connectors
System Board Connectors
See Figure 6-2 and Table 6-2 for the location and description of the system
board connectors.
Table 6-1. System Board Jumper Settings
Jumper Setting Description
NVRAM_CLR (default) The configuration settings in NVRAM are
retained at system boot.
The configuration settings in NVRAM are
cleared at next system boot.
PWRD_EN (default) The password feature is enabled.
The password feature is disabled.
book.book Page 122 Thursday, August 30, 2007 3:30 PM
