54 Installing System Components
Installing the Bezel
1
Hook the right end of the bezel into the bezel slot on the right side of the
system front plate
2
Rotate the other end of the bezel toward the front panel and press the
bezel onto the panel to engage the latch.
3
Lock the bezel.
Opening the System
CAUTION: Only trained service technicians are authorized to remove the system
cover and access any of the components inside the system. Before performing any
procedure, see your Product Information Guide for complete information about
safety precautions, working inside the computer and protecting against
electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system
from the electrical outlet and peripherals.
2
Extend the system out of the rack to the locked position. If the system is
installed on static rails, remove the system from the rack and place it on a
work surface.
3
To remove the system cover, loosen the thumbscrew at the back of the
system. See Figure 3-3.
4
Slide the cover backward about 1.3 cm (0.5 inch), and grasp the cover on
both sides.
5
Carefully lift the cover away from the system.
book.book Page 54 Thursday, August 30, 2007 3:30 PM
