Installing System Components 63
Removing a Hard Drive
The procedures for removing and installing SATA or SAS hard drives are the
same.
CAUTION: Only trained service technicians are authorized to remove the system
cover and access any of the components inside the system. Before performing any
procedure, see your Product Information Guide for complete information about
safety precautions, working inside the computer and protecting against
electrostatic discharge.
1
Open the system. See "Opening the System" on page 54.
2
If applicable, remove the optical drive.
Remove the optical drive if you are removing hard drive 0. See "Removing
the Optical Drive" on page 60.
3
Disconnect the power and interface cables from the hard drive.
The interface cables for SATA hard drives are connected to the system
board. See Figure 6-2 for the location of the system board connectors.
The interface cables for SAS hard drives are connected to a controller card.
4
Pull up on the plunger that secures the hard-drive carrier to the chassis.
See Figure 3-7 and Figure 3-8.
5
Slide the hard-drive carrier backward and lift the carrier out of the chassis.
See Figure 3-7 and Figure 3-8.
book.book Page 63 Thursday, August 30, 2007 3:30 PM
