Installing System Components 53
Opening and Closing the System
The system is enclosed by an optional bezel and cover. To upgrade or
troubleshoot the system, remove the bezel and cover.
Removing the Bezel
1
Unlock the bezel. See Figure 3-2.
2
Unlatch the left end of the bezel and rotate it away from the front panel.
3
Unhook the right end of the bezel and pull the bezel away from the
system.
Figure 3-2. Installing and Removing the Optional Bezel
1 key lock 2 bezel
2
1
book.book Page 53 Thursday, August 30, 2007 3:30 PM
