Installing System Components 89
Control Panel Assembly (Service-Only
Procedure)
Removing the Control Panel Assembly
CAUTION: Only trained service technicians are authorized to remove the system
cover and access any of the components inside the system. Before performing any
procedure, see your Product Information Guide for complete information about
safety precautions, working inside the computer and protecting against
electrostatic discharge.
1
Open the system. See "Opening the System" on page 54.
2
Disconnect the control panel cables. See Figure 3-20.
3
Using a #2 Phillips screwdriver, remove the two screws that secure the
control panel assembly to the chassis. See Figure 3-20.
4
Carefully lift the back of the control panel assembly to clear the chassis
mounting studs, and remove the assembly from the system.
book.book Page 89 Thursday, August 30, 2007 3:30 PM
