Dell PowerEdge R310 User Manual

Installing System Components 127
Installing a Redundant Power Supply
1 Verify that both power supplies are the same type and have the same
maximum output power.
NOTE: The maximum output power (shown in watts) is listed on the power
supply label.
2 If applicable, remove the power supply blank. See "Removing the Power
Supply Blank" on page 127.
3 Slide the new power supply into the chassis until the power supply is fully
seated and the release latch snaps into place. See Figure 3-21.
NOTE: If you unlatched the cable management arm in step 2 of the previous
procedure, relatch it. For information about the cable management arm, see
the system’s rack documentation.
4 Connect the power cable to the power supply and plug the cable into a
power outlet.
CAUTION: When connecting the power cable, secure the cable with the
Velcro strap.
NOTE: When installing, hot-swapping, or hot-adding a new power supply in a
system with two power supplies, allow several seconds for the system to recognize
the power supply and determine its status. The power-supply status indicator turns
green to signify that the power supply is functioning properly. See Figure 1-6.
Removing the Power Supply Blank
If you are installing a second power supply, remove the power supply blank in
bay PS2 by pulling outward on the blank.
CAUTION: To ensure proper system cooling, the power supply blank must be
installed in power supply bay PS2 in a non-redundant configuration. Remove the
power supply blank only if you are installing a second power supply.
Installing the Power Supply Blank
NOTE: Install the power supply blank only in power supply bay PS2.
To install the power supply blank, align the blank with the power supply bay
and insert the blank into the chassis until it clicks into place.
R310HOM.book Page 127 Thursday, March 4, 2010 1:03 AM

Dell PowerEdge R310 Specifications

General

Tcase	72.7 °C
Bus type	DMI
Stepping	B1
FSB Parity	No
Processor code	SLBJH
Processor cache	8 MB
Processor cores	4
Processor model	X3470
System bus rate	2.5 GT/s
Processor series	Intel Xeon 3400 Series
Processor socket	LGA 1156 (Socket H)
Processor threads	8
Processor codename	Lynnfield
Motherboard chipset	Intel® 3420
Processing Die size	296 mm²
Processor frequency	2.93 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 2x8, 4x4
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	22
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	774 M
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	800, 1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
HDD size	3.5 \
Optical drive type	DVD-RW
Total storage capacity	500 GB
Maximum storage capacity	8 TB
Number of HDDs installed	-
Memory slots	6x DIMM
Internal memory	2 GB
Graphics card	G200eW
LAN controller	Broadcom BCM5716
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express slots version	2.0
Power supply	350 W
Compatible operating systems	Windows Server Novell Linux Solaris10
Chassis type	Rack (1U)
Processor ARK ID	42932
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	610 mm
Width	434 mm
Height	42.4 mm
