60 Using the System Setup Program and UEFI Boot Manager
Integrated Devices Screen
Option Description
User Accessible
USB Ports
(All Ports On default)
Enables or disables the user-accessible USB ports.
Options are All Ports On, Only Back Ports On, and All
Ports Off.
Internal USB Port
(On default)
Enables or disables the internal USB port.
Embedded NIC1 and
NIC2
(Enabled default)
Enables or disables the operating system interface of the
NIC1 and NIC2 controllers. (The NICs may also be
accessed through the system’s management controller).
Embedded Gb NIC1
(Enabled with PXE
default)
Enables or disables the embedded NICs. PXE support
allows the system to boot from the network. Enabled
with iSCSI Boot option is available if the NIC on board
supports iSCSI.
Embedded Gb NIC2
(Enabled default)
Enables or disables the embedded NICs.
MAC Address Displays the MAC address for the NIC.
OS Watchdog Timer
(Disabled default)
Sets a timer to monitor the operating system for activity,
and aids in recovery if the system stops responding.
When Enabled, the operating system is allowed to
initialize the timer. When Disabled, the timer is
not initialized.
NOTE: This feature is usable only with operating systems
that support WDAT implementations of the Advanced
Configuration and Power Interface (ACPI) 3.0b
specification.
Embedded Video
Controller
(Enabled default)
Enables or disables BIOS support for the integrated
video controller.
NOTE: This field can be disabled only if an add-in video
card is present. If this field is disabled, remote access
features such as virtual KVM are not available.
R310HOM.book Page 60 Thursday, March 4, 2010 1:03 AM

Dell PowerEdge R310 Specifications

General

Tcase	72.7 °C
Bus type	DMI
Stepping	B1
FSB Parity	No
Processor code	SLBJH
Processor cache	8 MB
Processor cores	4
Processor model	X3470
System bus rate	2.5 GT/s
Processor series	Intel Xeon 3400 Series
Processor socket	LGA 1156 (Socket H)
Processor threads	8
Processor codename	Lynnfield
Motherboard chipset	Intel® 3420
Processing Die size	296 mm²
Processor frequency	2.93 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 2x8, 4x4
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	22
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	774 M
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	800, 1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
HDD size	3.5 \
Optical drive type	DVD-RW
Total storage capacity	500 GB
Maximum storage capacity	8 TB
Number of HDDs installed	-
Memory slots	6x DIMM
Internal memory	2 GB
Graphics card	G200eW
LAN controller	Broadcom BCM5716
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express slots version	2.0
Power supply	350 W
Compatible operating systems	Windows Server Novell Linux Solaris10
Chassis type	Rack (1U)
Processor ARK ID	42932
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	610 mm
Width	434 mm
Height	42.4 mm
