Installing the Keyboard
1. Connect the keyboard-data cable to the system board.
NOTE: Ensure that you fold the keyboard-data cable in perfect alignment.
2. Press the keyboard in its compartment.
3. Tighten the screws to secure the keyboard to the computer.
4. Press over the cross section of the following keys to secure the keyboard to the computer:
a) <R> , <T> , <F> and <G> keys
b) over the <9> key
c) NUMLOCK <9> key
19

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell Precision Mobile Workstation M4700 and is the answer not in the manual?

Dell Precision Mobile Workstation M4700 Specifications

General IconGeneral
RAMUp to 32GB DDR3
WirelessWi-Fi 802.11a/b/g/n, Bluetooth 4.0
ChipsetIntel QM77 Express
ProcessorIntel Core i5 or i7
GraphicsNVIDIA Quadro K1000M, K2000M or AMD FirePro M4000
Display15.6-inch HD (1366x768) or FHD (1920x1080)
StorageUp to 750GB HDD
Operating SystemWindows 7, Windows 8
Battery6-cell (60Wh) or 9-cell (97Wh)
PortsUSB 3.0, USB 2.0, HDMI, VGA, RJ-45, eSATA
Optical DriveDVD-ROM, DVD+/-RW
