Dell Precision Mobile Workstation M4700 User Manual

a) base cover
b) battery
4. Follow the procedures in After Working Inside Your Computer .
Removing the Secondary Memory
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the:
a) battery
b) keyboard trim
c) keyboard
NOTE: The secondary memory is located below the keyboard.
3. Pry the retention clips away from the memory module until it pops up. Lift up the memory module and remove it from
the computer.
Installing the Secondary Memory
1. Insert the secondary memory into the memory socket.
2. Press the clips to secure the memory module to the system board.
3. Install the:
a) keyboard
b) keyboard trim
c) battery
4. Follow the procedures in After Working Inside Your Computer .
Removing the Optical Drive
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the:
a) battery
b) base cover
3. Remove the screw that secures the optical drive to the computer.
21

Dell Precision Mobile Workstation M4700 Specifications

General

RAM	Up to 32GB DDR3
Wireless	Wi-Fi 802.11a/b/g/n, Bluetooth 4.0
Chipset	Intel QM77 Express
Processor	Intel Core i5 or i7
Graphics	NVIDIA Quadro K1000M, K2000M or AMD FirePro M4000
Display	15.6-inch HD (1366x768) or FHD (1920x1080)
Storage	Up to 750GB HDD
Operating System	Windows 7, Windows 8
Battery	6-cell (60Wh) or 9-cell (97Wh)
Ports	USB 3.0, USB 2.0, HDMI, VGA, RJ-45, eSATA
Optical Drive	DVD-ROM, DVD+/-RW
