Create a Layer 2 input policy map by specifying the keyword layer2 with the policy-map-input
command.
2. After you create an input policy map, do one or more of the following:
Applying a Class-Map or Input QoS Policy to a Queue
Applying an Input QoS Policy to an Input Policy Map
Honoring DSCP Values on Ingress Packets
Honoring dot1p Values on Ingress Packets
3. Apply the input policy map to an interface.
Applying a Class-Map or Input QoS Policy to a Queue
To apply a class-map or input QoS policy to a queue, use the following command.
• Assign an input QoS policy to a queue.
POLICY-MAP-IN mode
service-queue
Applying an Input QoS Policy to an Input Policy Map
To apply an input QoS policy to an input policy map, use the following command.
• Apply an input QoS policy to an input policy map.
POLICY-MAP-IN mode
policy-service-queue <number> qos-polcy
Honoring DSCP Values on Ingress Packets
Dell Networking OS provides the ability to honor DSCP values on ingress packets using Trust DSCP
feature.
The following table lists the standard DSCP definitions and indicates to which queues Dell Networking OS
maps DSCP values. When you configure trust DSCP, the matched packets and matched bytes counters
are not incremented in the show qos statistics.
Table 61. Default DSCP to Queue Mapping
DSCP/CP hex
range (XXX)xxx
DSCP Definition Traditional IP
Precedence
Internal Queue ID DSCP/CP decimal
111XXX Network Control 3 48–63
110XXX Internetwork
Control
3 48–63
101XXX EF (Expedited
Forwarding)
CRITIC/ECP 2 32–47
100XXX AF4 (Assured
Forwarding)
Flash Override 2 32–47
011XXX AF3 Flash 1 16–31
Quality of Service (QoS)
801
