Installing the optional I/O module (HDMI/VGA/DP/Serial/PS2)
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
NOTE: The optional PS2 module comes with a custom Dell adapter cable that is required to access the PS2 I/O ports. Plug
in the adapter cable to access the PS2 I/O and COM ports of your computer.
NOTE: This is an example of the procedure and installation steps are applicable for optional I/O module (HDMI/VGA/DP/
Serial/PS2).
The following images indicate the location of the optional I/O module and provide a visual representation of the installation
procedure.
Steps
1. To remove the dummy metal bracket, insert a flat-head screwdriver in the hole of the bracket. Push the bracket to release
the bracket, and then lift the bracket out from the system.
NOTE: This step applies if you are upgrading the system with no existing I/O module.
60 Removing and installing Field Replaceable Units (FRUs)
