AH Motion Controller – Operation Manual
9-34
_9
Error code Description
LED indicator status
CPU
Module
BUS FAULT
MS
NS
16#A0FB
The data exchange between AH10DNET and AH CPU
failed.
The red
light blinks.
The green
light is ON.
The green
light is ON.
16#A0FC
Errors occur in the slaves, on the module of an
AHRTU-DNET backplane, or on the AHRTU-DNET
backplane connection.
The red
light blinks.
The red
light blinks.
The green
light is ON.
9.2.9. AH10PFBM-5A
Error
code
Description
LED indicator status
CPU
MODULE
BUS FAULT
RUN
SYS
DP
16#A001
The master is not set.
The red
light blinks.
The green
light is ON.
The green
light is ON.
The green
light blinks.
16#A003
The master station enters the test mode.
The red
light blinks.
The green
light is ON.
The green
light is ON.
The green
light is ON.
16#A005
A timeout occurs when chips inside the
master station communicate.
The red
light blinks.
The green
light is ON.
The green
light is ON.
The green
light is ON.
16#A00B
A timeout occurs when AH10PFBM-5A
exchanges data exchange with a PLC.
The red
light blinks.
The green
light is ON.
The green
light is ON.
The green
light is ON.
16#A402
The PLC does not assign the I/O mapping
area to the master.
The red
light is ON.
The green
light is ON.
The green
light is ON.
The green
light is ON.
16#A404
Master initializing error
The red
light is ON.
The green
light is ON.
The green
light is ON.
The green
light is ON.
16#A406
Internal storage unit error
The red
light is ON.
The green
light is ON.
The green
light is ON.
The green
light is ON.
16#A407
Data exchange unit error
The red
light is ON.
The green
light is ON.
The green
light is ON.
The green
light is ON.
16#A408
Master serial number detection error
The red
light is ON.
The green
light is ON.
The green
light is ON.
The green
light is ON.
16#A4E2
The master detects that all the slaves are
offline.
The red
light is ON.
OFF
The green
light is ON.
The red light
is ON.
The master detects that some of the slaves
are offline.
The red
light is ON.
OFF
The green
light is ON.
The red light
blinks.
16#A4E6
The master detects that an error occurs in
the module connected to AHRTU-PFBS-5A.
The red
light is ON.
The green
light is ON.
The green
light is ON.
The green
light is ON.
9.2.10. AH10PFBS-5A
Error code Description
LED indicator status
CPU MODULE
BUS FAULT RUN NET
16#A4F0
The node address of AH10PFBS-5A exceeds the valid
range.
The red light is
ON.
The green
light is ON.
The green
light is ON.
16#A4F1
Internal hardware error
The red light is
ON.
The green
light is ON.
The green
light is ON.
16#A4F2
Parameter error
The red light is
ON.
The green
light is ON.
The green
light is ON.
16#A4F3
Configuration error
The red light is
ON.
The green
light is ON.
The green
light is ON.
16#A4F4
GPIO detection error
The red light is
ON.
The green
light is ON.
The green
light is ON.
16#A4F5
AH10PFBS-5A enters the mode of factory test.
The red light is
ON.
The green
light is ON.
The green
light is ON.
