Delta AHCPU560-EN2 Series User Manual

Chapter 8 CIP Object
8-17
8_
8.9 Port Object (Class ID: 16#F4)
It describes the communication interfaces that are present on the device and visible to CIP, including USB, EtherNet/IP
and more.
 Service Code
Service
Code
Service Name
Support
Description
Class Attribute Instance Attribute
16#01 Get_Attributes_All X V
Returns a predefined listing of this
objects attributes
16#0E Set_Attribute_Single V V
Returns the contents of the
specified attribute.
 Class
 Class ID：16#F4
 Instance
 16#00：Class Attribute
 16#01：Instance Attribute
 16#N：Instance #N Attribute
 When Instance = 0, the Class Attributes are listed below.
Class
Attribute
Name
Access
Rule
Data Type Values Description
16#01 Revision Get UINT 1 Revision of this object
16#02 Max Instance Get UINT 2
Maximum instance number of this
object
16#03 Number of Instance Get UINT 2
Number of object instances currently
created at this class level of the
device
16#08 Entry Port Get UINT 1 Communication port for EtherNet/IP
16#09
Port Instance Info
Get
ARRAY of
STRUCT of
--
Port Instance information: Port Type
+ Port Number
Port Type UINT
16#01
16#04
Port1: Blackplane
Type: 16#01
Nunber: 16#01
Port2: Ethernet Port
Type: 16#04
Number: 16#02
Port Number UINT
16#01
16#02
 When Instance = 1, the Instance Attributes are listed below.
Instance
Attribute
Name
Access
Rule
Data Type Values Description
16#01 Port Type Get UINT 16#04
EtherNet/IP, refer to the following
※1
16#02 Port Number Get UINT 16#01 Identify each communication port
16#03
Link Object
Get
STRUCT of --
Identify Object attached to this port.
Path length + Link Path
Path Length UINT 16#02 Path length
Link Path EPATH 20 65 24 01 Path segment: 16#
