AS Series Module Manual
3- 8
_3
CR# Name Description
Atr. Defaults
6: 40 ms
7: 50 ms
8: 60 ms
9: 70 ms
10: 80 ms
11: 90 ms
12: 100 ms
22
Channel Alarm Setup
0: open channel alarm
1: close channel alarm
bit0: channel 1
bit1: channel 2
bit2: channel 3
bit3: channel 4
0: warning
1: alarm
bit8: error in the power supply
bit9: error in the module hardware
bit10: error in calibration
R/W 0
23
The minimum scale
range for channel 1
When the format is set to integer in HWCONFIG,
the scale range is invalid.
For analog-
digital modules, it is much more
convenient if the system can convert digital values
to floating-
point values for earier understanding.
Here you can set the minimum and maximum scale
ranges of corresponding floating-point values for
channels.
For example, if the scale range for an analog to
digital input channel is ±10.0 V, it indicates the
maximum value is +10.0 V and the minimum value
is -10.0 V.
If the scale range fo
r an analog to digital input
channel is 4 mA ~ 20 mA. It indicates the maximum
R
-10.0
24
25
The minimum scale
range for channel 2
-10.0
26
27
The minimum scale
range for channel 3
-10.0
28
29
The minimum scale
range for channel 4
-10.0
30
31
The maximum scale
range for channel 1
10.0
32
33
The maximum scale
range for channel 2
10.0
34
35
The maximum scale
range for channel 3
10.0
36
