Delta AS200 Series User Manual

AS Series Operation Manual
2-79
_2
RJ-45 Pin Definition
1 TX+ 2 TX- 3 RX+ 4 N/C
5 N/C 6 RX- 7 N/C 8 N/C
2.10.3 Function Card Weights
AS-
F2AD
AS-
F2DA
AS-
F422
AS-
F485
AS-
F232
AS-
FCOPM
AS-
FEN02
AS-
FPFN02
Weight
30 g
30 g
22 g
29 g
26 g
29 g
51 g
51 g
2.11 Power Supply Module Specifications
2.11.1 General Specifications
 AS-PS02/AS-PS02A
Item
Specifications
Supply voltage
100–240 VAC (-15% to +10%)
50/60 Hz±5%
Action
specifications
If the input power supply is larger than 85 VAC, the power supply module can
function normally.
Allowable
instantaneous
power failure time
If the instantaneous power failure time is less than ten milliseconds, the power
supply module keeps running.
Fuse
2.5A/250 VAC
Inrush current
＜70A@115 VAC
24 VDC output
AS-PS02: 2 A for internal use: the CPU and the modules.
AS-PS02A: 1.5 A for internal use: the CPU and the modules;
0.5 A for external use.
Power protection
The 24 VDC output is equipped with the short circuit protection and the
overcurrent protection.
Surge voltage
withstand level
1,500 VAC (Primary-secondary), 1,500 VAC (Primary-PE), 500 VAC
(Secondary-PE)
Insulation voltage
Above 5 MΩ
The voltage between all inputs/outputs and the ground is 500 VDC.
Ground
The diameter of the ground should not be less than the diameters of the
cables connected to the terminals L and N.
Weight
AS-PS02
270 g
AS-PS02A
310 g
