Delta AS200 Series User Manual

AS Series Operation Manual
2-5
_2
Item
AS324MT-A / AS332T-A /
AS332P-A
AS228T-A / AS228P-A
AS228R-A / AS218TX-A
AS218PX-A / AS218RX-A
Remark
for more details on
Ethernet specificaitons
USB port
Mini USB
Storage interface
SD Card (Micro SD); maximum storage: 32G
Real-time clock
Years, months, days, hours, minutes, seconds and
weeks
*Batteries (CR1620) are
not included.
Function card interface
2x function cards,
supporting
communication card,
AD/DA analog function
cards
None
CANopen DS301 (Master)
Maximum node: 64; maximum bytes: 2000
*A function card AS
-
FCOPM is required for
AS300 Series.
CANopen DS301 (Slave)
Maximum PDO: 8; maximum bytes: 8
2.2.2 Electrical specifications
Model
Item
AS332T-A/
AS332P-A/
AS324MT-A
AS320T-B/
AS320P-B
AS300N-A
AS228T-A/
AS228P-A
AS218TX-A/
AS218PX-A
AS228R-A/
AS218RX-A
Supply voltage
24 VDC (20.4 VDC–28.8 VDC) (-15% to +20%)
Power
consumption (W)
3.6 3.6 3 3.4 4.9 4.3 / 5.3
Weight (g)
260
285
235
285
290
325 / 310
 Electrical specifications for the inputs on digital input/output module. The signals passing
through the inputs are 24 VDC signals.
Model
Item
AS332T-A
AS332P-A
AS320T-B
AS320P-B
AS324MT-A
Number of inputs
16 (X0.0-X0.15)
8 (X0.0-X0.7)
12 (X0.0-X0.11)
Connector type
MIL connector
Removable terminal blocks
MIL connector
Input type
Digital input
Input form
Direct current (sinking or sourcing)
X0.0+–X0.3+/X0.0- to
X0.3-: differential input
X0.4–X0.11: Direct current
(sinking or sourcing)
Input voltage/
current
24 VDC
5 mA
X0.0+
–X0.3+/X0.0- to X0.3-:
5 VDC, 5 mA
X0.4–X0.11: 24 VDC, 5 mA
Action
level
OFF→ON
>15 VDC
X0.0+
–X0.3+/X0.0- to X0.3-
:
>0.2VDC
X0.4–X0.11: >15VDC
ON→OFF
<5 VDC
X0.0+–X0.3+/X0.0- to
X0.3-: <-0.2VDC
X0.4–X0.11: <5VDC

Delta AS200 Series Specifications

General

Brand	Delta
Model	AS200 Series
Category	Control Unit
Language	English
