AS Series Operation Manual
1-2
1.1 Overview
This manual introduces the AS Series CPU functions, devices, module tables, troubleshooting, and so forth.
1.1.1 Related Manuals
The related manuals for AS Series programmable logic controllers are listed below.
AS Series Quick Start
This guides you in how to use the system before reading the related manuals.
AS Series Programming Manual
This introduces programming for the AS Series programmable logic controllers, basic instructions, and
applied instructions.
ISPSoft User Manual
This introduces the use of the ISPSoft software, programming language (Ladder, IL, SFC, FBD, and ST),
POUs, and tasks.
AS Series Hardware Manual
This introduces electrical specifications, appearances, dimensions, and so forth.
AS Series Operation Manual
This introduces CPU functions, devices, module tables, troubleshooting, and so forth.
AS Series Module Manual
This introduces special I/O modules such as network modules, analog I/O modules, temperature
measurement modules, motion control modules, and so forth.
1.1.2 Models Descriptions
Classification Model Name Description
Power supply
module
AS-PS02
Input: 100-240 VAC, 50/60 Hz
Output: 24VDC/2A, 48W (for PLC internal use)
AS-PS02A
Input: 100-240 VAC, 50/60 Hz
Output: 24VDC/1.5A, 36W (for PLC internal use)
Output: 24VDC/0.5A, 12W (for external use)
AS300 Series
CPU module
AS332P-A
CPU module, PNP output, 1x Ethernet port, 2x RS-485
ports, 1x USB port, 1x Micro SD interface, 2x function cards
(optional), supporting 32 I/Os (16DI+16DO) and up to 1024
I/Os. Program capacity:128K steps, high-density terminal
blocks
AS332T-A
CPU module, NPN output, 1x Ethernet port, 2x RS-485
ports, 1x USB port, 1x Micro SD interface, 2x function cards
(optional), supporting 32 I/Os (16DI+16DO) and up to 1024
I/Os. Program capacity:128K steps, high-density terminal
blocks
AS324MT-A
CPU module, NPN differential output, 1x Ethernet port, 2x
RS-485 ports, 1x USB port, 1x Micro SD interface, 2x
