Delta C2000 Plus Series User Manual

Appendix A. Modbus ProtocolC2000 Plus
A-11
Function
Name
Modbus
Address
Attribute
(Function
Code)
Size Description
Output
current
2104H R(03H)
Drive’s output current (XX.XX A). Decimal places can be
referred by the high byte of 211F
DC bus
voltage
2105H R(03H)
U16
Drive’s DC bus voltage (XXX.X V)
Output
voltage
2106H R(03H) Drive’s output voltage (XXX.X V)
Multi-step
speed
status
2107H R(03H)
Drive’s current running speed step given by multi-step speed
command (0 is main speed)
Counter
value
2109H R(03H) The present value of MI
Output
power factor
angle
210AH R(03H)
Drive’s output power factor angle (XXX.X°) (0.0–180.0°)
Output
torque
210BH R(03H) Output torque (XXX.X %)
Motor actual
speed
210CH R(03H) Actual motor speed (XXXXX rpm)
Number of
PG
feedback
pulses
210DH R(03H) Number of PG feedback pulses (0~65535)
Number of
pulse
commands
210EH R(03H) Number of PG2 pulse commands (0~65535)
Power
output
210FH R(03H) Drive’s output power (X.XXX kW)
Multi-
function
display
2116H R(03H)
Display the low word value (Pr.00-04) of user-defined items, the
value is low 16 bits data.
Maximum
user-
defined
value
211BH R(03H)
Maximum Operation Frequency (Pr.01-00) or Maximum User-
defined Value (Pr.00-26)
 When Pr.00-26 is 0, this value is equal to Pr.01-00 setting
 When Pr.00-26 is not 0, and the command source is
keypad, this value = Pr.00-24 × Pr.00-26 / Pr.01-00
 When Pr.00-26 is not 0, and the command source is 485,
this value = Pr.09-10 × Pr.00-26 / Pr.01-00
