Chapter 5 Parameters_VFD-B Series
Revision 10/2005, BE13, SW V4.08 5-65
Group 5: Multi-step speeds and PLC (Process Logic Control) parameters
05 - 00
a1st Step Speed Frequency Unit: 0.01
05 - 01
a2nd Step Speed Frequency Unit: 0.01
05 - 02
a3rd Step Speed Frequency Unit: 0.01
05 - 03
a4th Step Speed Frequency Unit: 0.01
05 - 04
a5th Step Speed Frequency Unit: 0.01
05 - 05
a6th Step Speed Frequency Unit: 0.01
05 - 06
a7th Step Speed Frequency Unit: 0.01
05 - 07
a8th Step Speed Frequency Unit: 0.01
05 - 08
a9th Step Speed Frequency Unit: 0.01
05 - 09
a10th Step Speed Frequency Unit: 0.01
05 - 10
a11th Step Speed Frequency Unit: 0.01
05 - 11
a12th Step Speed Frequency Unit: 0.01
05 - 12
a13th Step Speed Frequency Unit: 0.01
05 - 13
a14th Step Speed Frequency Unit: 0.01
05 - 14
a15th Step Speed Frequency Unit: 0.01
Factory Setting: 0.00
Settings 0.00 to 400.00 Hz
The Multi-Function Input Terminals (refer to Pr.04-04 to 04-09) are used to select one of the AC motor drive
Multi-step speeds. The speeds (frequencies) are determined by Pr.05-00 to 05-14 as shown above. They are
also used in conjunction with Pr.05-15 to 05-31 for PLC programs.
