Chapter 5 Parameters_VFD-B Series
5-10
Revision 10/2005, BE13, SW V4.08
Parameter Explanation Settings
Factory
Setting
Customer
34: Proximity sensor input for simple Index
function
35: Output shutoff stop (NO)
36: Output shutoff stop (NC)
04-10
Digital Terminal Input Debouncing
Time
1 to 20 (*2ms) 01
a04-11 ACI Analog Input Bias 0.00~200.00 % 0.00
00: Positive bias
04-12 ACI Bias Polarity
01: Negative bias
00
a04-13 ACI Input Gain 01 to 200 % 100
00: No ACI negative bias command
01: Negative bias: REV motion enabled
04-14
ACI Negative Bias, Reverse
Motion Enable/Disable
02: Negative bias: REV motion disabled
00
a04-15 AUI Analog Input Bias 0.00~200.00 % 0.00
00: Positive bias
04-16 AUI Bias Polarity
01: Negative bias
00
a04-17 AUI Input Gain 01 to 200 % 100
00: No AUI negative bias command
01: Negative bias: REV motion enabled
04-18
AUI Negative Bias
Reverse Motion Enable/Disable
02: Negative bias: REV motion disabled
00
04-19 AVI Analog Input Delay
0.00 to 10.00 sec 0.05
04-20 ACI Analog Input Delay
0.00 to 10.00 sec 0.05
04-21 AUI Analog Input Delay
0.00 to 10.00 sec 0.05
00: 0.01Hz
04-22
Analog Input Frequency
Resolution
01: 0.1Hz
01
04-23
Gear Ratio for Simple Index
Function
4 ~ 1000 200
04-24
Index Angle for Simple Index
Function
0.0 ~360.0
o
180.0
a04-25
Deceleration Time for Simple
Index Function
0.00 ~100.00 sec 0.00
Group 5 Multi-Step Speed and PLC Parameters
Parameter Explanation Settings
Factory
Setting
Customer
a05-00 1
st
Step Speed Frequency 0.00 to 400.00 Hz 0.00
a05-01 2
nd
Step Speed Frequency 0.00 to 400.00 Hz 0.00
