Chapter 5 Parameters_VFD-B Series
5-80
Revision 10/2005, BE13, SW V4.08
07 - 04
Number of Motor Poles Unit: 2
Settings 02 to 10 Factory Setting: 04
This parameter sets the number of motor poles (must be an even number).
07 - 05
Motor Parameters Auto Tuning Unit: 1
Factory Setting: 00
Settings 00 Disable
01 Auto Tuning R1 (motor doesn’t run)
02 Auto Tuning R1 + No-load Test (with running motor)
Start Auto Tuning by pressing RUN key after this parameter is set to 01 or 02.
When set to 01, it will only auto detect R1 value and Pr.07-01 must be input manually. When set to 02, the
AC motor drive should be unloaded and the values of Pr.07-01 and Pr.07-06 will be set automatically.
The steps to AUTO-Tuning are:
1. Make sure that all the parameters are set to factory settings and the motor wiring is correct.
2. Make sure the motor has no-load before executing auto-tuning and the shaft is not connected to any belt
or gear motor.
3. Fill in Pr.01-01, Pr.01-02, Pr.07-00, Pr.07-04 and Pr.07-08 with correct values.
4. After Pr.07-05 is set to 2, the AC motor drive will execute auto-tuning immediately after receiving a
”RUN” command. (Note: The motor will run!). The total auto tune time will be 15 seconds + Pr.01-09 +
Pr.01-10. Higher power drives need longer Accel/|Decel time (factory setting is recommmeded). After
executing, Pr.07-05 is set to 0.
5. After executing, please check if there are values filled in Pr.07-01 and Pr.07-06. If not, please press RUN
key after setting Pr.07-05 again.
6. Then you can set Pr.00-09 to 02/03 and set other parameters according to your application requirement.
NOTE
In vector control mode it is not recommended to have motors run in parallel.
NOTE
It is not recommended to use vector control mode if motor rated power exceeds the rated power of the AC motor
drive.
