Appendix B Accessories_VFD-B Series
B-26 Revision 10/2005, BE13, SW V4.08
B.3.2.3 PG-03 Terminal Descriptions
1. Terminals
Terminal Symbols Descriptions
+12V
Power Supply of the Encoder: +12V
Output Voltage: +12V
r5% 200mA
0V Common point for the power supply and the signal
Encoder signal input (select Encoder output type from FSW2)
Both single-phase input and two-phase input available
Maximum: 500KP/Sec
A/O, B/O
The Encoder signal output
Maximum: DC24V 50mA
Common point for signal grounding
2. Wiring Notes
a) Please use a shield cable to prevent interference. Do not run control wire parallel to any high voltage
AC power line (220V and up).
b) Connect shielded wire to E only.
c) Recommended wire size 0.21 to 0.81mm
2
(AWG24 to AWG18).
d) Wire length:
The Output Types of the
Encoder
Maximum Wire
Length
Wire Gauge
Output Voltage 50m
Open Collector 50m
Line Driver 300m
Complementary 70m
1.25mm
2
(AWG16) or above
To Next Page
