Denon AVR-1723 User Manual

111
PARTS LIST OF EXPLODED VIEW
z
Parts indicated by "nsp" on this table cannot be supplied.
z
P.W.B. ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts list and order replacement
parts.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
C1 nsp FRONT PCB ASS'Y 1613E3, 1713E3 COP12423D 1 *
C1 nsp FRONT PCB ASS'Y 1713E2 COP12423G 1 *
C1 nsp FRONT PCB ASS'Y 1713E1C, 1723E1C COP12423E 1 *
C1-1 - FRONT PCB
C1-2 - POWER KNOB PCB
C1-3 - HEADPHONE PCB
C1-4 - USB PCB
C1-5 - MIC PCB
C1-6 - FOR HDMI FFC CABLE PCB
C2 nsp MAIN PCB ASS'Y 1613E3, 1713E3 COP12425E 1 *
C2 nsp MAIN PCB ASS'Y 1713E2 COP12425F 1 *
C2 nsp MAIN PCB ASS'Y 1713E1C, 1723E1C COP12425G 1 *
C2-1 - MAIN PCB
C2-2 - CABLE PCB
C2-3 - HDMI CABLE PCB
C2-4 - CARD CABLE FIX PCB
C2-5 - TUNER PCB
C3 8U6391000600D DIGITAL PCB ASS'Y 1613E3 COP12428B 1 *
C3 8U6391000610D DIGITAL PCB ASS'Y
1713E3 COP12428C 1 *
C3 8U6391000620D DIGITAL PCB ASS'Y 1713E2 COP12428D 1 *
C3 8U6391000630D DIGITAL PCB ASS'Y
1713E1C COP12428E 1 *
C3 8U6391000640D DIGITAL PCB ASS'Y
1723E1C COP12428G 1 *
C3-1 - DIGITAL PCB
C3-2 - F-HDMI PCB
C4 nsp POWER PCB ASS'Y
1613E3, 1713E3 COP12427B 1 *
C4 nsp POWER PCB ASS'Y
1713E2 COP12427C 1 *
C4 nsp POWER PCB ASS'Y
1713E1C, 1723E1C COP12427D 1 *
C4-1 - SMPS PCB
C4-2 - REGULATOR PCB
z
C6 943101101320D TRANS,POWER AVR1613/1713/E3,(85.8X63) 1613E3, 1713E3 CLT5U052ZU 1 *
z
C6 943101101330D TRANS,POWER AVR1713/E2,(85.8X63) 1713E2 CLT5U052ZE 1 *
z
C6 943101101340D TRANS,POWER AVR1713/1723/E1C,(85.8X63) 1713E1C, 1723E1C CLT5U052ZH 1 *
C7 nsp ACSOCKET ASS'Y 1713E2 CWZPM5003TW91A 1
P1 943419100460D PANEL, SUB CGR1A534Z 1 *
P2 943416100700D WINDOW, FL 1713E3 CGU1A462X 1
*
P2 943416100710D WINDOW FL
1613E3, 1713E2,
1713E1C, 1723E1C
CGU1A462Y 1 *
P3 943412100710D KNOB, VOLUME BK CBN1A263 1
