PARTS LIST OF P.C.B. UNIT
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe modelE1C : China model
E1C : China model
FRONT PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 943239005300M I.C,OPAMP
HVIBA4560RF
Q1001 943219006820S TR KTC1027Y CVTKTC1027YT
Q1002 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q1003 943214500020S T.R,2SC3052 CVT2SC3052
Q1004 943214500020S T.R,2SC3052 CVT2SC3052
Q1005 00MHT600141B1 TR KTA1271Y HVTKTA1271YT
Q1006 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q1007 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q1008 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q1009 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q1011 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q1012 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
D1001 00D9630328409 DIODE,RECTIFIERS CVD1N4007ST
D1002 00D9630328409 DIODE,RECTIFIERS CVD1N4007ST
D1003 90M-HD302360R DIODE,ZENER,1/2W,6.8V CVDZJ6.8BT
D1004 00D9430087209 DIODE,ZENER,1/2W,24V CVDZJ24BT
D1005 90M-HD302450R DIODE,ZENER,1/2W,13V CVDZJ13BT
D1008 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1
D1009 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1
D1010 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1
D1011 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1
D1012 943176010090S L.E.D,(GREEN/RED5PI) CVDBLBJEGJ204L
D1019 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
D1020 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
D1401 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT
D1402 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT
D1403 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT
D1404 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
D1405 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
RESISTORS GROUP
R1001 nsp RES,CARBON(1/5W,1.8ohm,J)
CRD20TJ1R8T
R1004 nsp RES,CARBON(1/5W,1.8ohm,J) CRD20TJ1R8T
R1005 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R1006 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R1007 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
R1008 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R1009 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R1010 00MNN05393610 RES,CHIP(1608/5%/39Kohm) CRJ10DJ393T
R1011 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R1012 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1013 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1014 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1015 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1016 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R1017 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R1018 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1019 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1020 00MNN05332610 RES,CHIP(1608/5%/3.3Kohm) CRJ10DJ332T
R1021 00MNN05102610 RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T
R1022 00MNN05102610 RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T
R1023 00MNN05473610 RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T
