DIGITAL PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC711 236810057606S
I.C,HDMIMUX CVIADV3002BSTZ
IC721 943236012460S I.C,HDMITransceiver(LQFP-144P) CVIADV7623BSTZ
IC722 943248101050S I.C , OSD Serial Flash (AVR1613E3) 1613 E3 CVIANAM1674AV *
IC722 943248101060S
I.C , OSD Serial Flash (AVR1713E3) 1713 E3 CVIANAM1675AV *
IC722 943248101070S
I.C , OSD Serial Flash (AVR1713E2) 1713 E2 CVIANAM1676AV *
IC722 943248101090S
I.C , OSD Serial Flash (AVR1713E1C) 1713 E1C CVIANAM1677AV *
IC722 943248101100S
I.C , OSD Serial Flash (AVR1723E1C) 1723 E1C CVIANAM1678AV *
IC724 943239100760S
I.C,DE/MUX(8CHANALOG,TSSOP-16P) CVITC74VHC4051AFT *
IC751 nsp
I.C,DC-DCCONVERTER(3A,QFNT&R-38P) CVIEX3AV
IC752 nsp I.C,DC-DCCONVERTER(3A,QFNT&R-38P) CVIEX3AV
IC753 nsp I.C,DC-DCCONVERTER(3A,QFNT&R-38P) CVIEX3AV
IC754 nsp I.C,DC-DCCONVERTER(3A,QFNT&R-38P) CVIEX3AV
IC755 943239100730S I.C,SYSTEMRESET(4.8V,SOT-25A) CVIPST8448NR *
IC756 943239010400S
I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133
IC761 943243100860S I.C , MAIN MCU(AVR1613E3) 1613 E3 CVIANAM1662AV *
IC761 943243100870S
I.C , MAIN MCU(AVR1713E3) 1713 E3 CVIANAM1663AV *
IC761 943243100880S
I.C , MAIN MCU(AVR1713E2) 1713 E2 CVIANAM1664AV *
IC761 943243100900S
I.C , MAIN MCU(AVR1713E1C) 1713 E1C CVIANAM1665AV *
IC761 943243100910S
I.C , MAIN MCU(AVR1723E1C) 1723 E1C CVIANAM1666AV *
IC762 943239100720S
I.C,EEPROM(256KBIT,SOP-8P) CVIR1EX24256BSAS0A *
IC771 963239002150S
I.C,OCTALBUFFER/DRIVER CVISN74LVC244APWR
IC772 00D2623444902 I.C,QUAD2-INPUTANDGATE CVITC74VHC08FT
IC781 00D2623077900 IC,HEXINVERTER HVITC74VHCU04FT
IC782 236810062608S I.C,DIR CVILC89058W-E
IC783 943243100920S I.C , PLD(AVR1613/1713) CVIANAM1680AV *
IC791 943245100310S
I.C,DSPSHARC(LQFP-176P) CVIADSP21487KSWZ-2B *
IC792 943246012690S
I.C,64MSDRAM CVIW9864G6JH-6
IC793 943248101110S I.C , DSP(AVR1613/1713) CVIANAM1681AV *
IC811 236810086505S
I.C,ADC(96kHz24-Bit) CVIAK5358BET
IC812 236810073509S I.C,DAC(8CH192kHz24-Bit) CVIAK4358VQ
IC813 00D2631289900 EOLitemI.C,OPAMP(DUAL/LOWNOISE) CVIAZ4580MTR-E1
IC814 00D2631289900 EOLitemI.C,OPAMP(DUAL/LOWNOISE) CVIAZ4580MTR-E1
IC815 00D2631289900 EOLitemI.C,OPAMP(DUAL/LOWNOISE) CVIAZ4580MTR-E1
IC831 23681011260AS I.C,NetworkMediaprocessor(LFBGA-320P) CVIDM860A *
IC832 nsp
I.C,1GNANDFLASH(48P-TSOP1) CVIH27U1G8F2BTR-BC
IC833 246810063608S I.C,256MSDRAM CVIW9825G6JH-6
IC851 943239100700S I.C,EthernetTransceiver(QFN-24P) CVILAN8720ACPTR *
IC853 23671011050AS
I.C,IPODAUTHENTICATIONFROMD&M CVI23671011050AS_DM
IC854 943239100710S I.C,CURRENTLIMITE(1.5A,UDFN-6P) CVINCP380HMU15AATBG *
IC855 943239100690S
I.C,2CHDAC(32BIT,384KHZ,TSSOP-20P) 1713E3 CVIPCM5100PWR *
IC856 943239010400S
I.C,REGULATOR(3.3V/TO-252) 1713E3 CVINJM2845DL133
IC861 nsp I.C,HDMItransmitterwithI/PConverter(FBGA-289 CVISLI11131 *
IC871 nsp
I.C,HDMIBUFFER CVIAD8195ACPZ
IC891 943235100520S I.C,INPUTWITH8CHVOLUME(52PLQFP) CVINJU72340AFH3 *
IC901 90M-HC109700R
I.C,VIDEOS/W(JRC) CVINJM2595MTE1
Q7101 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q7102 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C
Q7103 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q7104 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C
Q7105 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q7106 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C
Q7107 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q7108 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C
Q7201 943215500020S T.R,RT1P141C(10K-10K) 1713E3 CVTRT1P141C
Q7202 943216500040S T.R,RT1N241C(22K-22K) 1713E3 CVTRT1N241C
Q7204 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q7205 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q7206 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q7501 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q7502 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111
Q7503 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
NOTE
:
When update Firmware, please
conrm a last version in SDI.
Use the service board after
updating it.
